Product introduction

Thermal class: 120℃,130℃,155℃,180℃,200℃,220℃.

Enamelled aluminum wire is a type of winding wire made by electric round aluminum rod which drawn by dies with special size, then over coated with enamel repetitiously.Enamelled Round Aluminum Wire is a fundamental part of a winding in every electrical machine or apparatus. Compared to fibrous insulations, enamelled aluminium wire offers a favourable space saving factor together with a high level of breakdown voltage. The main application of Enamelled Enamelled Aluminium wire is in winding of Motor and Transformers.

120 degree enamelled round wire is mainly used for oil immersed transformer.

130, 155 and 180 degree enamelled round wires are available for a wide range of magnetic coils.

The 200 degree enamelled round wire is capable of working at high temperature for a long time.

240-degree enamelled round wire is used in aerospace,mine,Marine and military industries.

Product range

Copper wire diameter range: 0.1 - 5.0 mm.

Aluminum wire diameter range: 0.2 - 6.5 mm.

Product Features

1. Low density allows coil weight reduction

2. Rapid heat dissipation

3. High cut through

4. Excellent heat shock

5. Perfect breakdown voltage

6. High heat resistance

7. Good solvent resistance

Product performance

1. Easy to bend, with good bending properties.

2. The insulation layer has strong adhesion and good insulation performance.

3. Strong scratch resistance, the surface is not easy to be scratched.

4. High mechanical strength, stable structure.

5. High paint removal efficiency, easy welding operation.

6. The paint film has high temperature resistance, can withstand high temperature environment for a long time, and some can resist refrigerant, transformer oil, etc., and solvent resistance, and has strong resistance to various solvents.

7. Some also have radiation protection capabilities and can play a role in some special environments.

Product Parameter

Product Application

1. Microwave transformers;

2. Windings with light weight, high conductivity, good heat resistance; Winding used for high frequency signal transmission;

3. Magnetic wire used in High Frequency transformer,common transformer, inductance coils, electromotors, household electromotors and micro-motors;

4. Magnet wires used in monitor deflection coil;

5. Magnet wires used in degaussing coil;

6. Other special magnet wire.

Product Packing

plywood wooden spool/bobbin, spool/bobbin common specifications: 250*400; 250*500; 250*600, one spool/bobbin wire weight 30~150kgs.

Carton box and pallet or plywood box, suitable for shipping by sea.
